Wire Pro|書籍線上App不用買

The WirePro App is a reference application developed to assist vendors, electrical engineers, and electricians with working with commercially available wire and the related parameters found in the National Electrical Code (NEC). WirePro has for Copper and Aluminum wire the ampacity table information found in NEC Table 310.16. WirePro also allows the user to apply temperature correction factors automatically based on the ambient temperature of use entered by the user. The correction factors associated with NEC Table 310.16 are stored in the program and applied when needed to the values from NEC Table 310.16. The table value and the corrected value are both shown on the user screen for comparison. In addition to this information, the Resistance (Xr) and Reactance (Xl) values from Table 9 of the NEC are displayed for each selected wire size and material. These values are then used along with the power factor, entered by the user, to calculate the Effective Impedance (Zeff), which is used to determine voltage drop. Along with these values, the “C” value is also displayed for each selected wire size and material. The “C” value is used in calculating available fault currents using the point-to-point method of fault current calculation. Finally, the conductor area circular mils is displayed for reference from Table 8 of the NEC.

NOTE: If you are unsure of how to apply these values, or if you just would like to have these values applied and calculated for you, please be sure and check out our other Apps on the App Store – “Circuit Pro” and “Service Pro”.
